STS S2M型橡胶同步带
| S2M型号不能做双面齿 | ||||||
| 规格 | 节线长 | 齿数 | 规格 | 节线长 | 齿数 | |
| S2M-60 | 60 | 30 | S2M-248 | 248 | 124 | |
| S2M-66 | 66 | 33 | S2M-252 | 252 | 126 | |
| S2M-80 | 80 | 40 | S2M-260 | 260 | 130 | |
| S2M-88 | 88 | 44 | S2M-262 | 262 | 131 | |
| S2M-90 | 90 | 45 | S2M-264 | 264 | 132 | |
| S2M-96 | 96 | 48 | S2M-266 | 266 | 133 | |
| S2M-98 | 98 | 49 | S2M-274 | 274 | 137 | |
| S2M-100 | 100 | 50 | S2M-276 | 276 | 138 | |
| S2M-102 | 102 | 51 | S2M-278 | 278 | 139 | |
| S2M-104 | 104 | 52 | S2M-282 | 282 | 141 | |
| S2M-106 | 106 | 53 | S2M-286 | 286 | 143 | |
| S2M-108 | 108 | 54 | S2M-288 | 288 | 144 | |
| S2M-110 | 110 | 55 | S2M-290 | 290 | 145 | |
| S2M-112 | 112 | 56 | S2M-302 | 302 | 151 | |
| S2M-114 | 114 | 57 | S2M-308 | 308 | 154 | |
| S2M-118 | 118 | 59 | S2M-310 | 310 | 155 | |
| S2M-120 | 120 | 60 | S2M-314 | 314 | 157 | |
| S2M-122 | 122 | 61 | S2M-320 | 320 | 160 | |
| S2M-124 | 124 | 62 | S2M-324 | 324 | 162 | |
| S2M-128 | 128 | 64 | S2M-334 | 334 | 167 | |
| S2M-130 | 130 | 65 | S2M-336 | 336 | 168 | |
| S2M-132 | 132 | 66 | S2M-340 | 340 | 170 | |
| S2M-134 | 134 | 67 | S2M-350 | 350 | 175 | |
| S2M-140 | 140 | 70 | S2M-352 | 352 | 176 | |
| S2M-142 | 142 | 71 | S2M-354 | 354 | 177 | |
| S2M-144 | 144 | 72 | S2M-370 | 370 | 185 | |
| S2M-146 | 146 | 73 | S2M-380 | 380 | 190 | |
| S2M-148 | 148 | 74 | S2M-388 | 388 | 194 | |
| S2M-150 | 150 | 75 | S2M-400 | 400 | 200 | |
| S2M-152 | 152 | 76 | S2M-418 | 418 | 209 | |
| S2M-154 | 154 | 77 | S2M-426 | 426 | 213 | |
| S2M-156 | 156 | 78 | S2M-436 | 436 | 218 | |
| S2M-158 | 158 | 79 | S2M-448 | 448 | 224 | |
| S2M-160 | 160 | 80 | S2M-452 | 452 | 226 | |
| S2M-162 | 162 | 81 | S2M-460 | 460 | 230 | |
| S2M-164 | 164 | 82 | S2M-480 | 480 | 240 | |
| S2M-172 | 172 | 86 | S2M-494 | 494 | 247 | |
| S2M-174 | 174 | 87 | S2M-520 | 520 | 280 | |
| S2M-176 | 176 | 88 | S2M-530 | 530 | 265 | |
| S2M-180 | 180 | 90 | S2M-556 | 556 | 278 | |
| S2M-182 | 182 | 91 | S2M-560 | 560 | 280 | |
| S2M-186 | 186 | 93 | S2M-584 | 584 | 292 | |
| S2M-190 | 190 | 95 | S2M-600 | 600 | 300 | |
| S2M-192 | 192 | 96 | S2M-604 | 604 | 302 | |
| S2M-196 | 196 | 98 | S2M-648 | 648 | 324 | |
| S2M-200 | 200 | 100 | S2M-688 | 688 | 344 | |
| S2M-202 | 202 | 101 | S2M-710 | 710 | 355 | |
| S2M-204 | 204 | 102 | S2M-750 | 750 | 375 | |
| S2M-210 | 210 | 105 | S2M-760 | 760 | 380 | |
| S2M-212 | 212 | 106 | S2M-810 | 810 | 405 | |
| S2M-214 | 214 | 107 | S2M-960 | 960 | 480 | |
| S2M-218 | 218 | 109 | S2M-984 | 984 | 492 | |
| S2M-220 | 220 | 110 | S2M-1224 | 1224 | 612 | |
| S2M-224 | 224 | 112 | S2M-3000 | 3000 | 1500 | |
| S2M-230 | 230 | 115 | ||||
| S2M-234 | 234 | 117 | ||||
| S2M-236 | 236 | 118 | ||||
| S2M-240 | 240 | 120 | ||||
订购需知
以上表格是STS-S2M型号的同步带系列中的一部分(模具增加，未及时更新)，同时我们还可以为您提供来图或者STS-S2M同步带样带生产加工，我们技术部也可按您提供STS-S2M型同步带齿数(节线长度=齿数*2.00), 宽度等参数来生产加工；如需要特殊规格型号或特殊性能要求（如阻燃、耐油、耐磨、抗静电、无毒等）本公司也可尽量满足客户的要求，给予定制。也可为您提供测绘同步带等服务。只要是您需要，我们就可以为您生产出您所需要的同步带，我们加工出来的STS-S2M同步带一定会让您满意。
